Solid Monitor Cases

The Scubacam range of solid aluminium monitor cases are heavy duty and rugged solutions for on-board framing and monitoring

These solid monitors are inteded underwater, as the weight can make the housing difficult to hold. Our Monitor Splash Bags are a lightweight alternative, and are better suited to out of water shots.

Our solid monitor cases come in two varieties - a sealed case designed to leave a monitor encased, and a hinged lid version enabling easy access to the monitor for adjustment or change.

Both units feature a waterproof 4 pin LEMO connector, and specialised combination HD video and power cable; and a RAM ball front port mount and 3" arm.

Monitor outputs inside the housing are fitted as standard with D-tap connectors to supply the required 8-16V input voltage. For a different connector type, please Contact Us.

Both varieties are intended for framing of shots only - no there is no provision for controlling the monitors once underwater.

Exterior Dimensions:

(WxHxD, Excludes cable connector)

5.5" Monitor Case: 205x130x75

Monitor output for housing*: £495

5.5" Monitor Case (With TVLogic F5A fitted): £3000

5.5" Monitor Case (Empty): £1750

5.5" Hinged Lid Monitor Case (Empty): £3000

Upgrade from old style cast case (Pre-2020): From £1950

*Required for use of both styles of case
